In the realm of water desalination, MD proudly presents the TFC 1812-50, a cutting-edge product that redefines industry standards. This comprehensive product introduction caters to professionals, buyers, and global dealers seeking a detailed understanding of the product's features, specifications, and applications.
The product is an exceptional desalination membrane that has been crafted with precision and expertise to deliver optimal performance in water treatment. This cutting-edge product is the result of extensive research and development efforts by a team of experienced engineers and scientists, who have been working tirelessly to create a membrane that is both efficient and reliable.
At the core of this membrane lies a profound obligation to quality, which is obvious in each part of its plan and manufacturing process. MD has spared no expense to ensure that this product satisfies the highest industry standards, choosing only the best raw materials and employing cutting-edge manufacturing techniques.
Whether you're looking to purify drinking water or treat industrial wastewater, the product is sure to provide a reliable solution that meets your specific needs. With its exceptional quality, outstanding performance, and unparalleled durability, this desalination membrane is the perfect choice for anyone who demands nothing but the best.
Our product adheres to stringent international standards, ensuring compliance with regulatory requirements. The TFC 1812-50 is crafted with precision to deliver consistent and efficient water desalination results.
| Model | RD-1812-50 |
| Salt Rejection(%) | 96% |
| 96%Permeate Flow GPD(m³/d) | 50(0.19) |
| Effective Membrane Area ft2 (m2) | 4.4(0.4) |
| Operating Pressure psi(Mpa) | 60(0.41) |
| Max Operating Pressure psi(Mpa) | 150(1) |
| Model | A/mm | B/mm | C/mm | D1/mm | D2/mm |
| TFC-1812-50 | 298 | 46 | 17 | 21.5 | 22.5 |
The product boasts remarkable attributes, including high desalination efficiency, durability, and compatibility with various water sources. Its innovative design ensures optimal performance in diverse conditions.
The product's desalination membrane stands as a pinnacle of innovation in the field of water treatment, effectively and efficiently removing impurities, salts, and contaminants to produce water of the highest quality. Its advanced filtration capabilities make it an indispensable component in a wide array of water treatment systems, playing a critical role in ensuring the delivery of clean and potable water for a diverse range of applications.
With its ability to remove harmful substances and pollutants from water, the product membrane not only meets but surpasses industry standards, providing a level of water purity that is essential for human consumption, industrial processes, and environmental preservation. Its reliable performance and consistent output make it an ideal choice for applications ranging from residential water purification systems to large-scale industrial water treatment plants.
Operating on the principle of reverse osmosis, the product utilizes a semi-permeable membrane to separate water molecules from impurities, ensuring a reliable and efficient desalination process.
Testing Conditions:
Testing pressure: 60 psi (0.41MPa)
Temperature of testing solution: 25℃
Concentration of testing solution (NaCl): 250 ppm
pH of testing solution: 7.5-8
Recovery of single element: 15%
Range of salt rejection: ±2
Operating Limits:
Membrane Type: Polyamide
Max. Operating Temperature: 45℃
Max. Operating Pressure: 150 psi (1MPa)
Max. Input Water Rate: 2.0 GPM (7.6 LPM)
pH Range: 2-11
Max. Input: SDI 5
Free Chlorine Tolerance: < 0.1 ppm
High Desalination Efficiency: Achieves superior desalination results.
Durability: Long-lasting performance in challenging environments.
Versatility: Compatible with diverse water sources.
Innovative Design: Ensures optimal functionality.
The product finds applications in industries such as agriculture. Its versatility makes it an ideal choice for addressing various water desalination needs.
MD takes pride in offering OEM services, providing clients with the flexibility to customize the product according to specific requirements. Our commitment to customization ensures that the product aligns seamlessly with diverse applications.
To address common queries, refer to our FAQ section for detailed information on installation, maintenance, and troubleshooting. MD is dedicated to providing comprehensive support to our clients.
MD stands as a renowned manufacturer and supplier, specializing in advanced desalination solutions. Our commitment to quality is reflected in the TFC 1812-50, backed by a complete test report. We support OEM customization, ensuring fast delivery with tight packaging.
For those choosing a small climate chamber, reach out to us at info@md-desalination.com for personalized assistance. MD is your trusted partner for water desalination solutions, combining innovation, reliability, and expertise to meet the demands of a dynamic industry.
